2O Single-Post Parking Lift & Car Stacker

2O Single Post Parking Lift – 1-Post Car Stacker

The Kettp 2O is a single post parking lift — also called a 1-post car stacker or one-post parking lift — that uses just one self-standing column to store two vehicles, one above the other. With zero side columns, both vehicles get 100% free door opening and unobstructed access, making the 2O the narrowest-footprint solution in Kettp's parking lift range. It's powered by a hydraulic cylinder + chain drive and rated for 2,000KG.

Browse the full Kettp 2-level parking lift stacker range

Single Column, Zero Side Obstruction

Unlike Kettp's 2T two post parking lift, which needs columns on both sides, the 2O supports the entire platform from one front-centre post. This makes it the right choice when a garage bay is wide enough for the vehicle itself but not wide enough for a 2-post or 4-post system alongside it — ideal for narrow home garages and car condos.

Hydraulic Cylinder + Chain Drive

A hydraulic cylinder combined with a chain transmission delivers smooth, quiet lifting at the rated 2,000KG load, with an electric automatic lock release for one-button lowering and a manual override as backup.

Full-Range Mechanical Anti-Falling Lock

A ratchet-style mechanical lock engages at every height increment throughout the lifting stroke, holding the platform securely even during a complete power or hydraulic failure. Combined with a hydraulic overload-relief valve and 24V DC safe control circuit, the 2O is designed to CE Machinery Directive standards.

Easy Installation & Relocation

The reinforced base foot anchors directly into a standard concrete slab — no pit or special foundation required. The single-column design also makes disassembly and relocation straightforward, which is why the 2O is popular for car condos and rented garages where a future move is likely.

Frequently Asked Questions

What is the rated capacity of the 2O single post parking lift?
2,000KG (approx. 4,400 lbs), suitable for sedans, hatchbacks, and small to mid-size crossovers. For heavier vehicles, see Kettp's 2T two post lift (up to 2,700KG) or 2FS heavy duty 4 post lift (4,000KG).

How much floor space does the 2O require?
Only the platform footprint plus the compact base foot of the single column — no side space is consumed by columns, so the aisle width on both sides of the vehicle stays completely usable.

Can the 2O be installed outdoors?
Yes. An outdoor package with hot-dip galvanized hardware and an IP65-rated electrical enclosure is available for permanent outdoor installation.

Is the 2O easy to relocate?
Yes. Unbolt the base foot and remove the single column — a much simpler process than relocating a 2-post or 4-post system, making the 2O a popular choice for car condos and rented garages.

Applications

Tight home garages, car condos, auto dealership showrooms, and classic car collections rely on the 2O for unobstructed, space-saving vehicle storage. Contact Kettp's engineering team for a free CAD layout and factory-direct quote.
