2S Clear-Span Multi-Platform Parking Lift

2S Multi-Platform Parking Lift – Clear Span Triple-Wide

The Kettp 2S is a multi-platform parking lift that stores up to 6 vehicles in a single triple-wide module with zero columns between platforms. Each of the three platforms operates independently, and the system is expandable by adding modules to the row. Rated up to 2,500KG per platform, the 2S is built for auto dealerships, commercial lots, showrooms, and large private collections.

Browse the full Kettp 2-level parking lift stacker range

Clear-Span, Zero-Column Design

Unlike installing three separate 2FC four post car lifts side by side, the 2S uses a single H-steel structure with columns only at the outer edges — every bay is fully open with no posts between platforms, making vehicle entry and exit straightforward from any direction.

Independent Platform Operation

Each of the three platforms raises and lowers independently, so retrieving one vehicle never requires moving the others — an important advantage over shared-drive systems for busy dealership and commercial operations.

Motor + Chain Drive, Wall-Mountable Structure

A 3.7KW motor and chain drive system powers each platform, with a rated structural service life of 30+ years and seismic resistance rated to grade 7. The heavy-duty H-steel superstructure can be fixed to an existing building wall for added lateral stability — particularly useful in underground car parks and basement installations.

Technical Specifications

• Rated Capacity: up to 2,500KG per platform
• Max Vehicle Dimensions (L x W x H): 5,000 x 1,850 x 2,050MM
• Drive System: Motor + chain, one motor per platform
• Motor Power: 3.7KW
• Working Speed: 4-6 m/min
• Parking Cycle Time: ≤60 seconds
• Power Supply: 110-450V, 50 or 60Hz, 3 phase
• Operation: Push button or key switch
• Noise Level: ≤70dB
• Structural Service Life: ≥30 years
• Seismic Resistance: Grade 7
• Finishing: Powder coating or hot-dip galvanized

Frequently Asked Questions

How many vehicles can the 2S accommodate?
The standard triple-wide module parks 6 vehicles (3 elevated + 3 at grade). The system can be expanded by adding modules to the row, with each additional module sharing a column with the previous one.

Can each platform be raised and lowered independently?
Yes. Each of the three platforms operates independently of the other two, so you can retrieve any vehicle without moving the others.

Can the 2S be mounted to a building wall?
Yes. The H-steel superstructure can be structurally fixed to an existing building wall for additional lateral stability, which is especially useful for underground car parks and basement installations.

What is the rated capacity of the 2S?
Up to 2,500KG per platform, suitable for sedans, SUVs, crossovers, and light vans.

Applications

Auto dealerships, shopping centre parking, public parking lots, car storage facilities, and residential developments rely on the 2S alongside Kettp's 2FD double wide car lift to maximize vehicle storage per row. Contact Kettp's engineering team for a free CAD layout and factory-direct quote.
