2TPD Underground Pit Parking Lift - Two-Post Independent Parking System

The KETTP 2TPD underground parking lift is a two-level hydraulic pit parking system that moves vehicles vertically between pit and ground level. It is designed for projects that need independent parking, better land use, and a cleaner driveway or garage appearance than above-ground stackers.

This product targets buyer searches such as underground parking lift, pit parking lift, two-post underground parking system, hydraulic pit lift, independent car parking lift, and residential basement parking lift. For other semi-automatic options, visit KETTP semi-automatic parking systems.

Independent parking with a pit

The 2TPD allows vehicles to be parked or retrieved with no need to move the other car. The lift travels vertically from the pit to ground level, making it suitable for private garages, apartment basements, commercial underground parking, villas, and retrofit parking projects where visible equipment should be minimized.

Key specifications

Type: two-level two-post underground parking lift
Capacity per space: 2000-3000 kg
Platform width: 2100-2700 mm, customizable
Pit depth: 1800-2100 mm
Vertical travel: 2000-3500 mm, customizable
Drive system: hydraulic direct drive lift system
Control: wall-mounted key switch, remote control, or optional touchscreen

Options and project fit

Powder coating is available for indoor use, while hot-dip galvanizing, thickened galvanized plate, LED lighting, and noise dampening can be specified for outdoor or higher-comfort installations. KETTP can help confirm pit depth, vehicle clearance, platform size, and layout before production.

KEY FEATURES

Key Features of the KETTP 2TPD Underground Parking Lift

Independent parking operation allows either vehicle to be parked or retrieved without moving the other car.
Hydraulic vertical lift mechanism moves vehicles smoothly between pit and ground level.
Two-post pit parking structure supports single-width or double-width layouts for different project requirements.
Multiple safety protection devices support secure daily operation in residential and commercial parking projects.
Wall-mounted key switch control provides simple operation for underground parking lift users.
Custom platform width and pit depth help match site dimensions, vehicle size, and clearance needs.
Powder coating and hot-dip galvanizing options support indoor, outdoor, and higher-corrosion environments.

SPECIFICATIONS

Technical Specifications for the KETTP 2TPD Underground Parking Lift

Type: two-level two-post underground parking lift
Operation: independent parking system
Capacity per space: 2000-3000 kg
Number of spaces: single or double spaces, one or two vehicles wide
Vertical travel range: 2000-3500 mm, customizable
Platform width: 2100-2700 mm, customizable
Pit depth required: 1800-2100 mm
Drive mechanism: hydraulic direct drive lift system
Structure: steel frame with powder-coated or hot-dip galvanized finish
Power supply: 220 V or 380 V, 50/60 Hz, customizable
Control system: wall-mounted key switch panel
Motor power: 3-5.5 kW

OPTIONS

Customization Options for the KETTP 2TPD Pit Parking Lift

Capacity options: 2000 kg, 2500 kg, or project-based configuration up to 3000 kg.
Platform widths: 2100 mm standard, 2700 mm wide, or custom dimensions.
Pit depths: 1800 mm shallow, 2000 mm standard, or 2100 mm deep.
Finishing: powder coating for indoor use or hot-dip galvanizing for outdoor projects.
Controls: wall-mounted key switch, remote control, or optional touchscreen.
Power options: single-phase 220 V or three-phase 380 V.
Accessories: LED lighting, noise dampening, and thickened galvanized plate.
